This is the 800hp industrial/marine cam used in C16 and C18 Cat Engines. This is a drop in camshaft for 3406E/C15 engines looking for more performance out of their engine. We have used this cam in many of our own builds in the shop and have had great results.
This camshaft does not work well with small injectors like 8501's or 8502's. The nozzle holes are to small and this causes fuel pressure to build up to pressures that the injector internally can not tolerate. Common side effects of using this cam with small injectors on this cam are the engine fluttering under a load above 1500rpm and sometimes the injector will just simply miss.

NEW NO CORE

This is the ultimate overhaul kit for your 3406E Caterpillar! With no modifications to your block, use your stock 3406E rods and these custom cylinder packs to turn your 3406E 14.6L into a 16.2L engine! These kits have been extensively tested in the harshest conditions before being sold to the public, so that you, the customer can rely on another top quality product from IPD. This kit from us will offer everything you need to do an in-frame on the truck, leaving no room for guesswork when installing this engine kit.

Customers that have installed these kits report that they have had increased fuel mileage, increased torque, and a decrease in cooling system temperature. IPD has done some serious improvements to the liners in these kits vs the original equipment. Moving away from the traditional high carbon steel liner and upgrading to a chromoly liner with added molybdenum to prevent liner issues that the C18's were known to have.

This kit comes with a out of frame gasket set, for additional pricing without the out of frame gaskets please call.

This kit will fit any 3406E model from 5ek to Mbn engine serial.

This cylinder pack takes a special piston cooling nozzle part# 274-8359

These kits are special order and stock varies, these kits have been in high demand and keeping them in stock has been challenging. please call before you order!

These kits are for off road and performance use only. NO WARRANTY IS VAILABLE FOR THIS SPECIFIC KIT.

3406E/C15 .003'' undersized plate is recommended when your liner protrusions are too low to use the standard thickness plate. We use this plate 90% of the time, if we are changing just the head with the engine having several miles on it and we are not replacing liners. Liners tend to sink a couple thousandths after the engine has been built for sometime and this spacer plate will help get your protrusions back within spec.

We recommend using a new spacer plate with each overhaul. Lots of people decide to clean up the old spacer plate and reuse it but this is not a good idea. On the 3406E/C15 liner protrusion is crucial to making the head gasket last as long as the rest of the engine. If your liner protrusions are off just .0015 of an inch and then you use a old wore out spacer plate that may be off that same amount we guarantee you'll be back into the engine in a very short time. Don't let the cost of a spacer plate keep you from rebuilding the engine the right way. Once and done is cheaper than the time or labor to pull that head off again.

Brand New not remanufactured! Our cylinder heads may not be casted in the USA but we only use the best casting companies to supply our bare castings. Every head we sell goes thru a machine shop in the USA, and gets loaded with premium Inconel valves, Premium Hardened seats, guides and new dual concentric valve springs to keep vibration and harmonics in check. We know this is what makes Our cylinder heads stand out from the crowd. Most of our competitors just import their heads, already loaded with some cheap subpar valve train components that will make them the most profit. We believe in quality over quantity, we only sell what we use in our own shop!

Brand New not remanufactured! Our cylinder heads may not be casted in the USA but we only use the best casting companies to supply our bare castings. Every head we sell goes thru a machine shop in the USA, and gets loaded with premium Inconel valves, Premium Hardened seats, guides and new dual concentric valve springs to keep vibration and harmonics in check. We know this is what makes Our cylinder heads stand out from the crowd. Most of our competitors just import their heads, already loaded with some cheap subpar valve train components that will make them the most profit. We believe in quality over quantity, we only sell what we use in our own shop!

This head is fire ringed, which is a small stainless steel ring that pressed into a groove that is machined into the head. The stainless ring protrudes out of the head and crushes into the head gasket just behind where it seals combustion in the cylinder. This helps back up the head gasket fire ring, aiding in a more stabile head gasket. Think of the fire ring as a brace on a dam wall that will keep pressure from blowing out the dam wall when extra pressure is added.

.032 thickness liner shim

.063 liner shim

.0170 thickness liner shim

Standard thickness spacer plate for 3406E/C15. We recommend using a new spacer plate with each overhaul. Lots of people decide to clean up the old spacer plate and reuse it but this is not a good idea. On the 3406E/C15 liner protrusion is crucial to making the head gasket last as long as the rest of the engine. If your liner protrusions are off just .0015 of an inch and then you use a worn out spacer plate that may be off that same amount we garantee you'll be back into the engine in a very short time. Don't let the cost of a spacer plate keep you from rebuilding the engine the right way. Once and done is cheaper than the time or labor to pull that head off again.

C15 proprietary low pressure turbo has our proprietary 5x3 compressor wheel. Turbo provides significant CFM gains over the factory turbo. Built from new genuine Garrett turbo. Requires no core. This Turbo is capable of 1,500 crank horse power, will also work great as a daily driver upgrade.

Build any configuration of the borg warner sx410 series cat turbo you want.
Options are:
80mm inducer on compressor.

Exhaust housing options are:
1.32 / 1.45 / 1.58

All turbos are the 96mm exducer on turbine wheel.

Please call for availability as stock has been hard to keep.

This is the ultimate overhaul kit for your C15 accert!! With no modifications to your block, use your stock Accert rods and these custom cylinder packs to turn your C15 into a C17 engine! These kits have been extensively tested in the harshest conditions before being sold to the public, so that you, the customer can rely on another top quality product from IPD. This kit from us will offer everything you need to do an in-frame on the truck, leaving no room for guesswork when installing this engine kit.

Customers that have installed these kits report that they have had increased fuel milage, increased torque, and a decrease in cooling system temperature. IPD has done some serious improvements to the liners in these kits vs the original equipment. Moving away from the traditional high carbon steel liner and upgrading to a chromoly liner with added molybdenum to prevent liner issues that the C18's were known to have.

This kit requires a piston cooling nozzle 274-8359 to match the piston cooling hole in the bottom of the piston and wrist pin location. If the cooling nozzles are not changed damage may occur.

These kits are special order and stock varies, these kits have been in high demand and keeping them in stock has been challenging. please call before you order!

These kits are for off road and performance use only. NO WARRANTY IS VAILABLE FOR THIS SPECIFIC KIT.
